Dellorto PHBG 19mm DS carburetor original spigot

  • Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigot
Dellorto PHBG 19mm DS carburetor original spigotDellorto PHBG 19mm DS carburetor original spigotDellorto PHBG 19mm DS carburetor original spigotDellorto PHBG 19mm DS carburetor original spigotDellorto PHBG 19mm DS carburetor original spigot
    € 104,90
    Ex Tax: € 86,69
    Tomoshop A few left in stock A few left in stock
    Model: 200231
    Tomoshop price Without shipping costs. VAT info.

    Why Tomoshop.nl?

    *Read the shipping page for more info.
    Customer service

    Do you need some help or advice?

    Tomoshop info Check out our info center or contact us!

    Description

    Original Dellorto PHBG 19mm carburettor

    • Connection diameter of the manifold 24mm
    • Connection diameter of the air filter 32mm with adapter 38mm
    • Nozzles/jets suitable for this carburettor are Dellorto 5mm jets/nozzles
    • Carburettors are delivered with a 75 nozzle/jet.
    • Carburettors should always be cleaned before installation.
    • Cable choke control.
    • Spigotstyle
    • Adjustment on the left side
    • Dellorto 2631

    Standard jetting

    • 30 Slide
    • W9 needle
    • 75 Main jet
    • 262AN |Atomiser
    • 45 Idle jet
    • 60 Choke jet
    • 9450.1 Float – 4.0 grams

    With a matching manifold applicable to various Tomos models:

    • Tomos A3, A35, Quadro, Standard, Luxe, Flexer etc.

    With a matching manifold also universally usable for:

    • Kreidler Florett  / RMC /  RM /  Zundapp / Yamaha DT / TY / Honda MT / MB / MBX / NSR / MTX / NS1 / Kawasaki AR / Suzuki TSX / TS /  Puch / Maxi / E50.
    View more Read more
    Brand: Dell’Orto
    Model: 200231
    MPN: 2866
    Category: Carburation
    Carburetor / sets
    Mounting type: Spigot
    Carburetor diameter: 19mm
    Weight: 465 gram

    Dell’Orto began its activity in 1933 with the manufacture of carburettors for motorbikes. A constant evolution that today makes it a modern and fully integrated company at production level, making technological research its strong point. Large range for vintage mopeds and therefore also for your Tomos like Dellorto SHA, Dellorto PHBG and Dellorto PHVA parts.
