1 217835 CROWN PIECE-NOT AVAILABLE
2 213819 INNER STRUT
3 213824 RUBBER SLEEVE-NOT AVAILABLE
4 26288 SOCKET BOLT M6X25- STAINLESS STEEL
4 26288 SOCKET-HEAD CAP BOLT M6X25- STAINLESS STEEL
5 31932 RING 6
5 31932 RING 6
5 31932 RING 6
5 31932 RING 6
6 31845 SPRING SPRING B6
6 31845 SPRING SPRING B6
6 31845 SPRING SPRING B6
7 31075 NUT M6
7 31075 NUT M6
7 31075 NUT M6
8 217870 LOWER LEG R.-NOT AVAILABLE
9 217871 LOWER LEG L. NOT AVAILABLE
10 213821 SLEEVE-NOT AVAILABLE
11 217873 COVER PLATE-NOT AVAILABLE
12 25394 BOLT M8X35
13 31933 WASHER 8
13 31933 WASHER 8
14 213826 CLAMPING CONE
15 213827 HANDLEBAR CLAMP
16 25196 BOLT M6X40
16 26571 HEX BOLT M6X30
17 208911 STEERING HEAD LOCK-NOT AVAILABLE
18 213803 HEADLIGHT BRACKET
19 207620 SEE 227.470
20 200714 CUVETTE
20 200714 CUVETTE
21 44535 BALL 5MM
21 44535 BALL 5MM
22 200471 SEE 223.157
23 200558 SEE 223.155
24 200715 COVER CAP
25 200717 BALL HEAD NUT
26 206701 WASHER 0.7 MM
27 219349 STEERING HEAD NUT CLOSED
28 213804 FRONT MUDGUARD CHROME
29 217837 STABILISER-NOT AVAILABLE
30 26312 BOLT M8X12
31 26313 BOLT M8X16
32 31847 RONDELLE RESSORT B8
33 26286 BOLT M6X10
33 26286 BOLT M6X10
33 26286 BOLT M6X10
34 213805 MUDGUARD BAR
35 207462 SEE 234323
36 207313 SPREADER NAIL
